4ms WAV Recorder Eurorack Module

Record High-Fidelity Sound

The 4ms WAV Recorder records high-quality sound onto a microSD card, offering up to 96kHz, 24-bit stereo recording. This can also be configured to either 96kHz, 48kHz, or 44.1kHz, as well as both 24-bit and 16-bit, plus stereo or mono. A flexible recorder indeed! You can playback previous recordings or standard WAV files from the microSD card. The gain knob and LED level metre let you easily adjust the signal level from synths to smart phones, without clipping and creating audible distortion. The WAV Recorder can accept both modular signal level or line level.

Your Memory Card Is Your Limitation

There are no limits to how long you can record, this is only limited to the space that is available on your microSD card. Typical cards can hold hundreds of hours of samples. The WAV Recorder module can continuously record for as long as up to 2 weeks without stopping if using a 128GB card. It automatically breaks long recordings when reaching 6 hours, splitting them up into 4GB files. Conveniently, the 4ms WAV Recorder comes with a 16GB microSD card to get you started.

Features

Records high-fidelity, low-noise stereo WAV files onto microSD card
Up to 96kHz, 24-bit stereo recording
Configurable to 96kHz, 48kHz, or 44.1kHz
24-bit or 16-bit, mono or stereo
Accepts modular signal level or line level
Gain knob and LED level metre allows you to easily boost or cut any signal from synths to smartphones, without clipping
Audio can be monitored without recording, so WAV Recorder can also be used as a preamp for boosting line level signals to modular level
Playback previous recordings or standard WAV files on the microSD card
Playback and record activated by button press, or a trigger jack
Recording time and number of files are limited only by available space on card (typical cards can hold hundreds of samples)
Continuous recording feature automatically breaks long recordings (6 hours, typically) into multiple 4GB files
Large (128GB) card can record continuously for 2 weeks without stopping
Connects to the LISTEN modules for recording directly from the main output
24-bit 96kHz Codec (DAC and ADC)
Includes 16GB microSD card

Specifications
Width: 6hp
Depth: 25 mm
Power: 112 mA +12V, 12 mA -12V

Manufacturer product page here.
Product manual here.
