BeepBoop Electronics LO-FI Tape Sampler V5 Eurorack Module

The core of the LO-FI Tape Sampler was inspired by Peter Edwards of Casper Electronics and his experimentation with the ISD1820 sampler chip. The name “tape” is given to the module due to the Lo-fi sample rate which is similar to the classic Casio SK1 sampler keyboard.


Version 5 updates:

• Integrated microphone – panel mounted condenser microphone
• Microphone switch – record from the microphone or the audio in or mix both
• EOC output – end of cycle pulse out which can becomes a clock when the module is in loop mode
• MIX crossfader – mixing between the input signal and the sampler/filter output
• Normalised CV – Audio In is normalised to CV In for FM over recording and playback pitch
• CV LOCK switch – mute CV IN jack during REC mode
• Momentary loop – holding trig now loops playback
• Reactive TRIG input – DRY/WET MIX reacts to the TRIG input level

Original Features:

• High/low pitch range switch
• Attenuverter CV
• Increased output gain to 5v peak to peak using a active opamp circuit
• Expander headers
• Reduced end of sample “click”
• Lovingly hand soldered and built at Beepboop Electronics Workshop
• Includes power ribbon, mounting screws and 1 year Warranty

Specifications

• Width: 8hp
• Depth: 25mm
• Power: +12V 35mA / -12V 20mA

Manufacturer product page here.
