Zlob Modular MiniAtt Eurorack Dual Mute Attenuator Mixer Module

59.00 inc. VAT

48.76 ex. VAT

Bear in mind prices on the site are initially shown including Spanish VAT (21%).

After entering your shipping address at checkout prices on the site will update to show the correct VAT amount due to us based on your location. If purchasing from outside the EU, VAT, handling fees, and import duties will potentially be due on delivery.





Product Info


MiniAtt is a 2hp Dual Passive Attenuator, Offset Generator, Level Shifter, Mixer, and Mute Eurorack Module.

The newest 666 version (2021) can be powered and will provide Offset of 0-5V with nothing plugged into the “IN” for each channel controlled by each respective Potentiometer. The “Sum Out” will also be able to send out 0-10v~ volts depending on the setting of each Potentiometer. Both channels are normalled to the sum, so inserting a signal into an “OUT” will remove it from the “Sum Out.” Likewise, when inserting a cable into the IN it will remove the voltage normalization and act as a passive attenuator. In active mode the module can also be used to offset and level shift +5v to -5v signals to 0v to 5v (and other ranges in between) at the “Sum Out” with a waveform input on one channel and by using the normalled voltage offset from the other channel.

There will be signal loss at the “Sum Out” in passive mode. In active mode the “Sum Out” is buffered and there will be no signal loss. Great for cv or audio although the module ships with linear pots.

Specifications

  • Width: 2hp
  • Depth: 25mm
  • Power: +12V 10mA / -12V 5mA

Manufacturer product page here.
